50KVA Three Phase Voltage Stabilizer 3 Phase Automatic Voltage Regulator

Product Name: Three phase AC power voltage stabilizer

Product Brand: Wenma Power

Product Model: TNS(SVC、SJW)-50KVA

Rated Power: 50KVA/50000VA

Rated Frequency: 50-60Hz

Current Type: AC

Voltage Phase: Three phase

Input Voltage: 380V/440V/415V/440V/460V±20% (or tailored)

Input Current: In accordance with input voltage

Output Voltage: 380V/400V/415V/440V/460V±2% (or tailored)

Output Current: In accordance with output voltage

Waveform Distortion: Nil

Temperature Rise: ＜80℃

Dielectric Strength: 2000V/1minute

Product Size: 620mm*510mm*1340mm (Width*Depth*Height)

Product Weight: 200kg for reference

Product Usage: Voltage stabilization

Power Factor: 98%

Working Efficiency: 98%

Insulation Class: F

Insulation Resistance: ≥5MΩ

Protection functions: under-voltage, short circuit, over-load, over-voltage, over-current, time delay, phase failure, etc.

4. Q&A

① How long is the lead time after receiving my deposit?

It depends on the quantity of the order. If the quantity is not that large (less than 10 pcs), it is normally less than 10 days for us to prepare the products for you.

② How long is the warranty period?

Twelve-month warranty is provided by us after you purchase the product.

③ Is OEM and ODM acceptable?

Yes, absolutely it's acceptable. The product could be customized according to your needs.

④ How about the payment terms?

We accept TT/ or other payment methods convenient for both of us.

⑤ What certificates do you have?

We have ISO:9001 and CE certificates. And we can apply for more certificates if it is needed.

⑥ Would you support on-spot services?

If you have any question on the usage of the product, we could first provide remote guidance service for you. If necessary, on-spot services could be provided too.

⑦ Where is your factory?

We have factories and offices in Wenzhou, Zhejiang Province, Guangzhou, Guangdong Province, and Wuhan, Hubei Province, People's Republic of China

⑧ Could you please provide form A or form B for us?

Yes, certainly, it could be provided if necessary.
